MAG540 Infomir 4K
Original Infomir MAG 540 with Ethernet connection. Linux. Shipping worldwide, next day delivery.
Manufacturer: Infomir
Warranty (months): 24
Type of plug (if using)
Quantity
in stock: 595 unit/s
Total price: € 81,00
the price does not include VAT Shipping cost to your country
Detail information
Infomir MAG540 4K IPTV Settopbox with Linux System. Connection via Ethernet cable , speed 100Mbit/s.
MAG540 is a new chipset CPU IPTV set-top box from Infomir. Infomir MAG 540 using as HW 1 GB of RAM and 4 GB of flash memory.
MAG540 plays files with HEVC codec. This reduces the load on the network, even when it comes to streaming 4K content. Set-top box runs under Linux OS.
Supports 4K and HEVC, Linux OS, USB x 2 (3.0, 2.0), 1GB RAM, 4GB eMMC
Chipset : Amlogic S905Y4 Quad-core ARM Cortex-A35, 2000 MHz
Performance : 16500 DMIPS
RAM : 1 GB
Flash memory : 4 GB eMMC
Software
Operating system Linux 4.9
Middleware supported Pre-integrated Ministra TV platform from Infomir. It is possible to integrate operator applications into the image, customize or completely replace the image.
Interfaces
HDMI 2.1, Ethernet 100 Mbps, USB 2.0x1, USB 3.0x1
Sources of media content
PC and NAS in local network, Stream media protocols (RTSP, RTP, UDP, IGMP, HTTP), USB-devices
Audio & video
Audio codecs MPEG L1 / L2 / L3l, AAC-LC, HE AAC V1 / V2, APE, FLAC, Dolby Digital Plus
Audio formats AC3, ACC, APE, FLAC, M4A, MP3, OGG, WAV
Video modes PAL, NTSC, 576p, 720p, 1080p, 1080i, 2160p
Video codecs MPEG1 / 2 MP @ HL, MPEG4 part 2 (ASP), H.265 Main / Main 10@L5.1 High 2160p @ 60 fps (optional), H.264 AVC High@L5.1 2160p @ 30 fps, XviD, 3D video support
Video containers TS, AVI, MPEG, MP4, MOV, MKV, M2TS, VOB
Image formats JPEG, PNG, BMP, RAW
Subtitles DVB, PGS, SRT, SSA / ASS, SUB, Teletext subs, WebVtt, Closed captions
Playlist formats M3U, M3U8, PLS, CUE
Included in Package :
- Infomir MAG 540 4K IPTV Receiver
- Power Supply Unit (EU/US or UK - choose during ordering)
- Remote Control Unit + Batteries
- HDMI Cable
- Short User Manual
- Infomir License Label
Wifi connection not supported. For Wifi version, choose Infomir MAG 540w3.
Shipping worldwide from EU stock, next day delivery.
Discussion
Product Parameters
Software: LinuxConnectivity: Ethernet 100Mbit/s
RAM: 1GB
Flash Memory: 4 GB
